Hydraulic
8.3 Assembly of the hydraulic unit
motor 11 kW
4/2-valve
cover for cleaning
oil tank 180 l
Air-oil heat
exchanger
support
fluid level gauge
accumulator
charging unit
diaphragm
accumulator
return line filter
shaft sealing
mounting plate
missing with standard
hydraulics
