32
Common operations and display items
Rev0.02
TIME/VALUE dial
fig.06-05
The TIME/VALUE dial is used to change the cursor position,
values, or characters. In the case of values, these are
increased when the dial is turned clockwise, and reduced
when the dial is turned counterclockwise.
VALUE 1/PAN, VALUE 2, and VALUE 3 knobs
fig.06-07
These knobs can be used to change the values of parameters
indicated by knob icons ( ) on-screen.
Turn clockwise to increase a value and counterclockwise to
decrease it.
In addition, you can also use these knobs to make large changes in
pattern and loop phrase numbers when a pattern selection screen
for rhythm patterns, bass patterns, or loop phrases is displayed.
