Braillo 650 SF - Main Board - Connections

BRAILLO
l
B 650 SF
112
Audio
pre out
Not in use
Not in use
Ethernet
Not in use
Not in use
USB
Power
operator
panel
Signal
operator
panel
Data
Magnet racks
A B C D
Not
in use
Step
motor
Sync.
External
equip. (SF)
SD memory
card with
software
Spare
sensor
Cover
sensor
Beam
wheel
sensor
Paper
feed 2
sensor
Paper
feed 1
sensor
Out of
paper
sensor
El-unit
connect.
6.4 Main board - Connections
