Braillo 650 SF - Paper Roll Feeder - Assembly

BRAILLO
l
B 650 SF
16
2.4 Paper roll feeder - assembly
Motor
assembly
Friction bar
Friction
bar guides
Frame
Paper sensor
Shaft and
paper roll
Insert shaft
into paper roll
Ready for
mounting
Correction roll
Placing the paper roll
Crank to
lift/lower
paper roll
Laser beam
Sensor for empty
paper roll
