Braillo 650 SF - Stapling

BRAILLO
l
B 650 SF
129
Stapling
cylinder
7.11 Stapling
Please see chapter 7.25 “Staplers” for more infor-
mation on the staplers.
The stapling cylinder will move down and up
again to engage the staplers.
C6
V4
14
5 1 3
4 2
Stapling
Pneumatics schematic
Name Connection Input/Output
Valve V4 - Y12
Electrical information:
