BRAILLO
l
B 650 SF
9
Left-hand
side
Right-hand
side
PAPER ROLL
FEEDER
PRINTER AND
CUTTER
STAPLE AND
FOLD UNIT
Printer overview
Please see figure below:
Note that the “right-hand” and “left-hand” side are referred to as if you were standing behind the
Printer facing the opening where the paper is inserted into the Printer.
