BRAILLO
l
B 650 SF
96
Grease Grease Grease
Lubrication
This should be done every 500 running hours, or approximately once a year.
Lubricate all items marked “grease” on the gure below. (These are the only locations on the Printer
grease may be applied!). The Printer needs to be disassembled to do this lubrication, so it is recom-
mend to do this at the same time as the regular 500 hour service.
Use a universal grease with molybdensuld. Use no oil.
Grease Grease
