Brainboxes ED-549 - Storage and Operating Environment Guidelines; LED Indicators

Ethernet Analogue DIO
Product Manual V1.3
© Copyright Brainboxes Ltd
Page 12 of 100
Storage and Operating Environment Guidelines
ED Range – Industrial
Operating Temperature:
-30°C to +80°C
Storage Temperature:
-40°C to +85°C
Humidity:
5% to 95% non-condensing
Housing:
IP 20 rated non-conducting polyamide case
Integrated DIN rail mount
LED indicators
There are 4 LEDs on the ED devices representing the status, expansion port, Ethernet link and the activity. The
table below lists these LEDs and the meaning of the colours.
Status LED
Green
Device Ready
Flashing Yellow
Changing Settings
Flashing between Red & Green
Querying IP
Flashing Green and Red
User performing Hard Reset
Flashing between Green & Red/Yellow
IP address diagnostic
Flashing between Green & Yellow
Initialization diagnostic
Expansion
Flashing Red
RS-485 Comms error
Flashing Green
RS-485
Link LED
Green light on
Network Link Established
Flashing Green
Network Data RX/TX
Activity
Flashing Green
Input Read
Flashing Red
Input Error
