Range settings and data formats
ED-549 Analogue input type settings (rr)
Type Code
Input Type
Data Format
+ Full Scale
- Full Scale
05
±2.5V
Engineering unit
+2.5000
-2.5000
% of FSR
+100.00
-100.00
2’s complement hex
7FFF
8000
06 or 0D
±20mA
Engineering unit
+20.000
-20.000
% of FSR
+100.00
-100.00
2’s complement hex
7FFF
8000
07
+4 to +20mA
Engineering unit
+20.000
+04.000
% of FSR
+100.00
+000.00
2’s complement hex
FFFF
0000
08
±10V
Engineering unit
+10.000
-10.000
% of FSR
+100.00
-100.00
2’s complement hex
7FFF
8000
09
±5V
Engineering unit
+5.0000
-5.0000
% of FSR
+100.00
-100.00
2’s complement hex
7FFF
8000
04 or 0A
±1V
Engineering unit
+1.0000
-1.0000
% of FSR
+100.00
-100.00
2’s complement hex
7FFF
8000
03 or 0B
±500mV
Engineering unit
+500.00
-500.00
% of FSR
+100.00
-100.00
2’s complement hex
7FFF
8000
0C
±150mV
Engineering unit
+150.00
-150.00
% of FSR
+100.00
-100.00
2’s complement hex
7FFF
8000
1A
0 to +20mA
Engineering unit
+20.000
+00.000
% of FSR
+100.00
+000.00
2’s complement hex
FFFF
0000
3A
±75mV
Engineering unit
+75.000
-75.000
% of FSR
+100.00
-100.00
2’s complement hex
7FFF
8000
3B
±250mV
Engineering unit
+250.00
-250.00
% of FSR
+100.00
-100.00
2’s complement hex
7FFF
8000
