$aaA
Applies to: ED-549
Description:
Command to read the data from every analogue input channel in hexadecimal format.
Command Syntax:
$aaA[CS](CR)
$
Delimiter character
aa
Address of the device in hexadecimal format (00 to FF)
A
Command to read from every analogue input channel in hexadecimal format
[CS]
Checksum
(CR)
Carriage Return
Response:
Valid Command: >(Data)[CS](CR)
Invalid Command: ?aa[CS](CR)
>
Delimiter for a valid command
?
Delimiter for an invalid command
aa
Address of the device which responded
(Data)
Data from all the analogue channels in hexadecimal format
[CS]
Checksum
(CR)
Carriage Return
Examples:
Send command to read the analogue data.
Command: $01A(CR)
Response: >200004E42000055C200005D42000064C200006C42000073C200007B42000082C(CR)
