$aa9nts
Applies to: ED-560
Description:
Command to set the specified channel full scale range configuration. This is an alternative form of the
$aa9nttss command, for compatibility with software designed for other devices.
Command Syntax:
$aa9nts[CS](CR)
$
Delimiter character
aa
Address of the device to be configured in hexadecimal format (00 to FF)
9
Command to set the channel range code
n
Command to specify the input channel where n is the input channel number
t
Command to specify the type code where t is the second character of the type code from the
‘Range settings and data formats’ table
s
Command to specify the output slew rate – not implemented on current firmware, use a value
of 0 to ensure that the behaviour does not change when the feature is added.
[CS]
Checksum, if enabled
(CR)
Carriage Return
Response:
Valid Command: !aa[CS](CR)
Invalid Command: ?aa[CS](CR)
!
Delimiter for a valid command
?
Delimiter for an invalid command
aa
Address of the device which responded
[CS]
Checksum
(CR)
Carriage Return
Examples:
Send command to set the first channel to the 0-10V range: n=0, t=2, s=0
Command: $019020(CR)
Response: !01(CR)
Send command to set the fourth channel to the 4-20mA range: n=3, t=1, s=0
Command: $019310(CR)
Response: !01(CR)
