~aa5n
Applies to: ED-560
Description:
Command to set the safe value of channel n to the present output.
Command Syntax:
~aa5n[CS](CR)
~
Delimiter character
aa
Address of the device to be configured in hexadecimal format (00 to FF)
5
Command to set the safe value
n
The channel to be set (0 to F)
[CS]
Checksum
(CR)
Carriage Return
Response:
Valid Command: !aa[CS](CR)
Invalid Command: ?aa[CS](CR)
!
Delimiter for a valid command
?
Delimiter for an invalid command
aa
Address of the device
[CS]
Checksum
(CR)
Carriage Return
Examples:
Set the safe value of channel 2 to 5.13.
Command: #012+05.130(CR)
Response: >(CR)
Command: ~0152(CR)
Response: !01(CR)
