$aa1Ci
Applies to: ED-549
Description:
Command to perform a span calibration on a specified channel.
Command Syntax:
$aa1Ci[CS](CR)
$
Delimiter character
aa
Address of the device to be calibrated, in hexadecimal format (00 to FF)
1C
Command to perform the span calibration
i
Channel on which to perform the span calibration
[CS]
Checksum
(CR)
Carriage Return
Response:
Valid Command: !aa[CS](CR)
Invalid Command: ?aa[CS](CR)
!
Delimiter for a valid command
?
Delimiter for an invalid command
aa
Address of the device which responded
[CS]
Checksum
(CR)
Carriage Return
Examples:
Send the command to set the span calibration of channel 0 to the voltage being applied to the line.
Command: $011C0(CR)
Response: !01(CR)
Note: Calibration must be enabled using ~aaEV before using this command.
