$aa7CiRrr
Applies to: ED-549
Description:
Command to set the specified channel full scale range configuration.
Command Syntax:
$aa7CiRrr[CS](CR)
$
Delimiter character
aa
Address of the device to be configured in hexadecimal format (00 to FF)
7
Command to set the channel range code
Ci
Command to specify the input channel where i is the input channel
Rrr
Command to specify the type code where rr is the type code from the ‘Range settings and
data formats’ table
[CS]
Checksum, if enabled
(CR)
Carriage Return
Response:
Valid Command: !aa[CS](CR)
Invalid Command: ?aa[CS](CR)
!
Delimiter for a valid command
?
Delimiter for an invalid command
aa
Address of the device which responded
[CS]
Checksum
(CR)
Carriage Return
Examples:
Send command to set the first channel to ±5V Full Scale Range.
Command: $017C0R09(CR)
Response: !01(CR)
Send command to set the fourth channel to ±500mV
Command: $017C3R0B(CR)
Response: !01(CR)
