Brainboxes ED-549 - Analogue Input Type Settings (Tt); Command List

Ethernet Analogue DIO
Product Manual V1.3
© Copyright Brainboxes Ltd
Page 56 of 100
ED-560 Analogue input type settings (tt)
Type Code
Input Type
Data Format
+ Full Scale
Minimum
30
0 to +20mA
Engineering unit
20.000
00.000
% of FSR
+100.00
+000.00
2’s complement hex
FFF
000
31
+4 to +20mA
Engineering unit
20.000
04.000
% of FSR
+100.00
+000.00
2’s complement hex
FFF
000
32
0 to +10V
Engineering unit
10.000
00.000
% of FSR
+100.00
+000.00
2’s complement hex
FFF
000
Command List
Command
Response
Description
Supported
Devices
%aannttccff
!aa
Set device configuration
All Devices
#**
No Response
Synchronised sampling
ED-549
#aa
>(Data)
Read analogue input of all channels
ED-549
#aan
>(Data)
Read the analogue input of one channel
ED-549
#aan(Data)
>
Set the output value for one channel
ED-560
$aa0Ci
!aa
Perform span calibration on a channel
ED-549
$aa1Ci
!aa
Perform zero calibration on a channel
ED-549
$aa2
!aannttccff
Read the device configuration
All Devices
$aa4
>aaS(Data)
Read the synchronised data
ED-549
$aa4n
!aa
Set power on value of channel n
ED-560
$aa5
!aas
Read the reset status
ED-560
$aa5vv
!aa
Enable/disable the channel
ED-549
$aa6
!aa(Data)
Read the channel enable/disable status
ED-549
$aa6n
!aa(Data)
Read the output value for one channel
ED-560
$aa7CiRrr
!aa
Configure the range for one channel
ED-549
$aa7n
!aa
Read power-on value for one channel
ED-560
$aa8Ci
!aaCiRrr
Read the range configuration for one channel
ED-549
$aa9nttss
!aa
Configure the range for one channel
ED-560
$aa9nts
!aa
Configure the range for one channel
ED-560
$aa9n
!aattss
Read the range configuration for one channel
ED-560
$aaA
>(Data)
Read the analogue inputs of all channels
ED-549
