Brainlab KICK 2 - Technical Specifications

7.3.2 Technical Specifications
Monitor Cart and Medical Computer Unit
Specification Value
Electrical Specifications
AC input 100 VAC - 240 VAC
Frequency 50/60 Hz
Power consumption
3 A @ 100 VAC
1.5 A @ 240 VAC
CMOS Battery 3V CR2032 Lithium Battery 210 mAh
Processor
Intel
®
Core i5 4th generation with 2.0 GHz
RAM 8 GB
Supported I/O
• 2 USB 2.0
• 3 USB 3.0
• Potential equalization
• S-Video In
• 2 LAN 1 GBit/s connection
• CVBS
• DVI-I
Mass Storage Internal Solid State Disk (SSD) 2.5” 240 GB
Audio Loudspeaker integrated in the Monitor Cart base
Display 21.5”, FHD resolution
Touchscreen Projected capacitive touchscreen
Fuse
5 x 20 mm
6.3 A / 250 V
T H
DVI Converter
Please refer to the Brainlab instruction leaflet, Converter Kit DVI to S-Video.
Technical Specifications
82 System and Technical User Guide Rev. 1.3 Kick 2 Navigation Station
