7.4.3 Electromagnetic Immunity
Electromagnetic Immunity Tests
The Kick 2 is intended for use in professional healthcare facilities only. The following lists all
applicable immunity tests and standards, as well as the used compliance levels:
Immunity Test Standard IEC 60601-1-2 Test
Level
Compliance Level
Electrostatic Discharge –
Contact
IEC 61000-4-2
±8 kV ±8 kV
Electrostatic Discharge –
Air
±2 kV, ±4 kV, ±8 kV,
±15 kV
±2 kV, ±4 kV, ±8 kV,
±15 kV
Radiated RF EM Fields IEC 61000-4-3
3 V/m
80 MHz to 2.7 GHz
80% AM at 1 kHz
3 V/m
80 MHz to 2.7 GHz
80% AM at 1 kHz
Proximity Fields from RF
Wireless Communication
Equipment 2450 MHz
IEC 61000-4-3
28 V/m 28 V/m
Proximity Fields from RF
Wireless Communication
Equipment – 5240 MHz,
5500 MHz, 5785 MHz
9 V/m 9 V/m
Electrical Fast Transient/
Burst – Input AC Power
Port
IEC 61000-4-4
±2 kV
100 kHz repetition
frequency
±2 kV
100 kHz repetition fre-
quency
Electrical Fast Transient/
Burst – Signal Input/
Output Ports
±1 kV
100 kHz repetition
frequency
±1 kV
100 kHz repetition fre-
quency
Surge – Input AC Power
Port Line-to-Line
IEC 61000-4-5
±0.5 kV, ±1 kV ±0.5 kV, ±1 kV
Surge – Input AC Power
Port Line-to-Ground
±0.5 kV, ±1 kV, ± 2
kV
±0.5 kV, ±1 kV, ± 2 kV
Surge – Input/Output Ports
Line-to-Ground
± 2 kV ± 2 kV
Conducted Disturbances
Induced by RF
IEC 61000-4-6
3 V
0.15 MHz to 80 MHz
6 V
80% AM at 1 kHz
3 V
0.15 MHz to 80 MHz
6 V
80% AM at 1 kHz
Power Frequency Magnet-
ic Field
IEC 61000-4-8
30 A/m
50 Hz or 60 Hz
30 A/m
50 Hz or 60 Hz
Voltage Dips
IEC 61000-4-11
0% U
t
; 0.5 cycle
At 0, 45°, 90°, 135°,
180°, 225°, 270° and
315°
0% U
t
; 1 cycle and
70% U
t
; 25/30 cy-
cles
Single phase at 0°
Complies
Voltage Interruptions
0% U
t
; 250/300 cy-
cle
Complies
