Broadcom BCM7405 - Figure 1-30: EBI Asynchronous Write Cycle between Two PCI Cycles

2/24/2008 9T6WP
Preliminary Hardware Data Module BCM7405
06/29/07 Functional Description
Broadcom Corporation
Document 7405-1HDM00-R Peripherals Page 1-87
Figure 1-30: EBI Asynchronous Write Cycle Between Two PCI Cycles
PCI_CLK
PCI_AD[15:0]
(EBI_DATA[15:0])
PCI_IRDYb
(EBI_ADDR[21])
PCI_TRDYb
(EBI_TAb)
PCI_DEVSELb
(EBI_ADDR[23])
PCI_FRAMEb
EBI Address
EBI_RWb
EBI_DSb
EBI_RDb[1:0]
EBI_WEb[1:0]
PCI_AD[31:16]
(EBI_ADDR[15:0])
PCI_CBE[3:0]
(EBI_ADDR[19:16])
EBI_CSb
PCI_STOPb
(EBI_ADDR[22])
EBI Address
PCI
Addr
PCI
Addr
PCI
CMD
PCI Data
PCI Data
PCI Byte Enable
PCI
Addr
PCI
Addr
PCI
CMD
PCI Data
PCI Byte Enable
Async Mode EBI Write CyclePCI Write Cycle PCI Read Cycle
PCI
Data
EBI Data
EBI Address
EBI Valid Tsize EBI_TSIZE[1:0]
EBI_ADDR[25:24]
PCI_REQb
PCI_GNTb
EBI_REQb
EBI_GNTb
Deassert PCI_GNTb and
ready to grant EBI when
PCI bus is idle
