Broadcom BCM7405 - Supported Modes; Table 1-10: DVI Supported Modes; Table 1-11: ITU-656 Supported Modes

2/24/2008 9T6WP
BCM7405 Preliminary Hardware Data Module
Functional Description 06/29/07
Broadcom Corporation
Page 1-54 Video and Graphics Display Document 7405-1HDM00-R
Supported Modes
Table 1-10 illustrates the exact modes of support for the DVI output.
.
Table 1-10: DVI Supported Modes
S/N
Active Video Format @
Frame Rate
Typical Names Applicable Standard
Total Resolution
Including
Blanking
1 720x480i@60 Hz HDMI/DVI 480i_60hz EIA/CEA 861-B 1716x525
2 720x480p@60 Hz HDMI/DVI 480p_60hz EIA/CEA 861-B 858x525
3 1280x720p@60 Hz HDMI/DVI 720p_60hz EIA/CEA 861-B 1650x750
4 1920x1080i@60 Hz HDMI/DVI 1080i_60hz EIA/CEA 861-B 2200x1125
5 720x576i@50 Hz HDMI/DVI 625i_50hz EIA/CEA 861-B 1728x625
6 720x576p@50 Hz HDMI/DVI 625p_50hz EIA/CEA 861-B 864x625
7 1280x720p@50 Hz HDMI/DVI 720p_50hz EIA/CEA 861-B 1650x750
8 1920x1080i@50 Hz HDMI/DVI 1125i_50hz EIA/CEA 861-B 2200x1125
9 640x480@60 Hz DVI Safe Mode EIA/CEA 861-A 800X525
10 800x600@60 Hz SVGA VESA dmt09 1056x628
11 1024x768@60 Hz XGA VESA dmt09 1344x806
12 1280x720@59.94 Hz 720p video VESA dmt09 1664x748
13 1280x720@50 Hz 720p pal VESA dmt09 1632x741
14 1280x720@60 Hz 720p VGA VESA dmt09 1440x741
15 1280x768@60 Hz WXGA VESA dmt09 1664x798
16 1366x768@60 Hz TFT LCD Chi Mei Model V320B1-L01 1440x782
17 1366x768@60 Hz Sharp Monitor Broadcom Internal Specifications 1440x782
18 1366x768@60 Hz Sharp Monitor Inverted Sync Broadcom Internal Specifications 1440x782
19 1024x768@60 Hz Plasma TV Broadcom Internal Specifications 1126x800
Table 1-11: ITU-656 Supported Modes
S/N
Active Video Format @
Frame Rate
Typical Names Applicable Standard
Total Resolution
Including Blanking
1 720x480i@60 Hz 656 in NTSC mode ITU-BT 601 1716x525
2 720x576i@60 Hz 656 in PAL mode ITU-BT 601 1728x625
