Broadcom BCM7405 - Figure 1-41: DAC Audio Output Timing Diagram; Table 1-27: DAC Audio Output Timing Parameters

2/24/2008 9T6WP
BCM7405 Preliminary Hardware Data Module
Timing and AC Characteristics 06/29/07
Broadcom Corporation
Page 1-156 DAC Audio Output Timing Document 7405-1HDM00-R
DAC AUDIO OUTPUT TIMING
Figure 1-41: DAC Audio Output Timing Diagram
Table 1-27: DAC Audio Output Timing Parameters
Description Symbol Min Typical Max Units
Pulse width Tw 37 – – ns
