Broadcom BCM7405 - Table 1-8: Analog Video Encoder

2/24/2008 9T6WP
Preliminary Hardware Data Module BCM7405
06/29/07 Functional Description
Broadcom Corporation
Document 7405-1HDM00-R Video and Graphics Display Page 1-51
Table 1-8: Analog Video Encoder
S/N
Active Video Format@
Frame Rate
Typical Names Applicable Standard
Total Resolution
including Blanking
1 720x480i@60 Hz NTSC/480i SMPTE 170M-1999 1716x525
2 720x480i@60 Hz NTSC Macrovision AGC Type 1 Macrovision Proprietary 1716x525
3 720x480i@60 Hz NTSC Macrovision AGC and
Color Stripe Type 2
Macrovision Proprietary 1716x525
4 720x480i@60 Hz NTSC Macrovision AGC and
Color Stripe Type 3
Macrovision Proprietary 1716x525
5 720x480i@60 Hz NTSC - M/J (Japan) ITU-R BT.470-6 1716x525
6 720 x 240p@60 Hz Gaming Mode (North America
Set-top box)
Broadcom Internal Spec 1716x525
7 720x576i@50Hz SECAM ITU-470.6 1728x625
8 720x576i@50 Hz PAL ITU-R BT.470-6 1728X625
9 720x576i@50 Hz PAL Macrovision AGC Macrovision Proprietary 1728X625
10 720x480i@50 Hz PAL - M ITU-R BT.470-6 1716x525
11 720x576p@50 Hz 625p ITU-R BT.1358 864X625
12 720x576p@50 Hz 625p with Macrovision Macrovision Proprietary 864X625
13 720 x 480p@59.94 Hz 480p (483p), 525p SMPTE 293M-1996 858x525
14 720 x 480p@59.94 Hz 480p Macrovision Macrovision Proprietary 858x525
15 1280x720p@60 Hz 720p SMPTE 296M-2001 1650x750
16 1280x720p@50 Hz 720p_50hz SMPTE 296M-2001 1650x750
17 1920x1080i@60 Hz 1080i, 1125i SMPTE 274-1998 2200x1125
18 1920x1080i@50 Hz 1125i_50hz SMPTE 274-1998 2200x1125
19 1920x1080i@50 Hz 1250i SMPTE 295M-1997 2376x2150
20 1920x1080p@24 Hz 1080p_24Hz SMPTE 274-1998 2750x1125
21 1920x1080p@30 Hz 1080p_30Hz SMPTE 274-1998 2200x1125
