BCM7405 Preliminary Hardware Data Module
Hardware Signal Descriptions 06/29/07
Broadcom Corporation
Page 1-118 Pin Definition Notations Document 7405-1HDM00-R
1 16 - GPIO GPIO_033 STI/O PD 3.3 8 L32 Generic I/O port. Shared
with POD2CHIP_MDI2 /
PPKT_DATA2 /
PKT_DATA3
1 16 - GPIO GPIO_034 STI/O PD 3.3 8 L33 Generic I/O port. Shared
with POD2CHIP_MDI3 /
PPKT_DATA3 /
PKT_DATA4
1 16 - GPIO GPIO_035 STI/O PD 3.3 8 M32 Generic I/O port. Shared
with POD2CHIP_MDI4 /
PPKT_DATA4 /
PKT_SYNC2
1 16 - GPIO GPIO_036 STI/O PD 3.3 8 M33 Generic I/O port. Shared
with POD2CHIP_MDI5 /
PPKT_DATA5 /
PKT_SYNC3
1 16 - GPIO GPIO_037 STI/O PD 3.3 8 M34 Generic I/O port. Shared
with POD2CHIP_MDI6 /
PPKT_DATA6 /
PKT_SYNC4
1 16 - GPIO GPIO_038 STI/O PD 3.3 8 P31 Generic I/O port. Shared
with POD2CHIP_MDI7 /
PPKT_DATA7 /
UART_RXD_2
1 16 - GPIO GPIO_039 STI/O PD 3.3 8 M30 Generic I/O port. Shared
with POD2CHIP_MICLK /
PPKT_CLK / UART_TXD_2
/ EBI_ADDR_13
1 16 - GPIO GPIO_040 STI/O PD 3.3 8 T32 Generic I/O port. Shared
with CHIP2POD_MOVAL /
RMXP_VALID /
EBI_ADDR_16
1 16 - GPIO GPIO_041 STI/O PD 3.3 8 T33 Generic I/O port. Shared
with CHIP2POD_MOSTRT
/ RMXP_SYNC /
EBI_ADDR_17
1 16 - GPIO GPIO_042 STI/O PD 3.3 8 R33 Generic I/O port. Shared
with CHIP2POD_MDO0 /
RMXP_DATA0 /
EBI_ADDR_18
1 16 - GPIO GPIO_043 STI/O PD 3.3 8 R32 Generic I/O port. Shared
with CHIP2POD_MDO1 /
RMXP_DATA1 /
EBI_ADDR_19 /
NDS_SC_AUX_0
1 16 - GPIO GPIO_044 STI/O PD 3.3 8 P33 Generic I/O port. Shared
with CHIP2POD_MDO2 /
RMXP_DATA2 /
EBI_ADDR_20 /
NDS_SC_AUX_1
Table 1-19: Pin Descriptions (Cont.)
# of
Pins
Orcad Schematic
Block
Label I/O Res.
Tol.
(V)
Drv.
(mA)
Loc. Description
