2/24/2008 9T6WP
Preliminary Hardware Data Module BCM7405
06/29/07 Hardware Signal Descriptions
Broadcom Corporation
Document 7405-1HDM00-R Pin Definition Notations Page 1-127
1 17 - D3.3V VDDO V V 3.3 – AH25 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – AH27 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – AJ13 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – AH13 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – AH29 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – AP22 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – T34 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – AE34 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – AH19 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – AJ19 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – AJ23 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – U29 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – U28 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – AP7 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – AP33 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – AH23 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – AD29 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – AJ16 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – G10 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – P28 Digital Power Supply (3.3V
I/O ±10%)
1 17 - D3.3V VDDO V V 3.3 – P29 Digital Power Supply (3.3V
I/O ±10%)
VDDP (2.5V Digital Power) Balls – 8
1 19 - D2.5V VDDP V V 2.5 – R28 Digital Power Supply (2.5V
I/O ±10%)
Table 1-19: Pin Descriptions (Cont.)
# of
Pins
Orcad Schematic
Block
Label I/O Res.
Tol.
(V)
Drv.
(mA)
Loc. Description
