2/24/2008 9T6WP
BCM7405 Preliminary Hardware Data Module
Hardware Signal Descriptions 06/29/07
Broadcom Corporation
Page 1-132 Pin Definition Notations Document 7405-1HDM00-R
1 20 - D1.2V VDDC V V 1.2 – AD13 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AD14 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AD15 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AC13 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AC14 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AC15 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AE13 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AE14 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AE15 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – K12 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – K10 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – K11 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – L12 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – L10 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – L11 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – M12 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – M10 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – M11 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – N12 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – N11 Digital Power Supply (1.2V
core ±5%)
DDRV (1.8V DDR2 Power) Balls - 32
1 18 - DDR2 1.8V DDRV V V 1.8 – K6 Digital Power Supply
(DDR0) (1.8V I/O ±5%)
1 18 - DDR2 1.8V DDRV V V 1.8 – K7 Digital Power Supply
(DDR0) (1.8V I/O ±5%)
Table 1-19: Pin Descriptions (Cont.)
# of
Pins
Orcad Schematic
Block
Label I/O Res.
Tol.
(V)
Drv.
(mA)
Loc. Description
