Brocade MLX Series and NetIron XMR Hardware Installation Guide 171
53-1003821-01
Installing a NetIron XMR 32000 router
3
Installing a NetIron XMR 32000 router
This section describes how to install a NetIron XMR 32000 router:
Preparing the installation site
Before installing the router, plan the location and orientation relative to other devices and
equipment. For cooling purposes, allow a minimum of six inches of space between the sides, front,
and the back of the router and walls or other obstructions. If a router is installed within a perforated
enclosure, the perforations must cover at least 60 percent of the surface.
Since you will be using a mechanical lift to move and install the router, make sure you allow enough
working room.
NOTE
Make sure your site provides 200-240 AC power.
Ensure that the proper network and power cabling is installed in the site. For information on
cabling, refer to “NetIron XMR 32000 cable management” on page 178, “Installing NetIron XMR
32000 router power supplies” on page 188, and Attaching a management station” on page 193.
Unpacking a NetIron XMR 32000 router
The NetIron XMR 32000 router ships with the following items:
Router chassis with the card slots empty, and covered with upper and lower shipping panels
The appropriate number of interface modules, switch fabric modules, management modules,
and power supplies
A total of 32 slot blanks
Insertion or extraction tool for use with RJ 45 and fiber-optic connectors
If any items are missing, contact the place of purchase
Removing the NetIron XMR 32000 from the shipping crate
The NetIron XMR 32000 router ships in a wooden crate, bolted to an inner pallet, and resting on an
outer pallet. To remove the router, the crate must be in the upright (vertical) position.
Before unpacking the router, the site should be prepared as described in “Preparing the installation
site” on page 171. You will need these tools:
A forklift or pallet jack with a minimum weight limit of 550 lb to move the router while still on
the pallet.
A mechanical lift with a minimum weight limit of 350-lb limit to move the router off the pallet.
The ideal configuration is a counterweight base material lift with a metal lift plate installed in
place of the forks. The metal plate should be no wider than 17 inches, so that it will fit between
the rack mount rails.
A strap to stabilize the router while it is being moved on the mechanical lift
A power drill
A large Phillips screwdriver attachment
A 7/16 inch socket wrench attachment
