Installing a NetIron XMR 16000 router
3
Installing a NetIron XMR 16000 router in a rack
Keep the following precautions in mind when installing a NetIron XMR 16000 router in a rack:
DANGER
A fully-populated NetIron XMR 16000 router is heavy. TWO OR MORE PEOPLE ARE REQUIRED
WHEN LIFTING, HANDLING, OR MOUNTING THESE DEVICES.
DANGER
Do not use the handles on the power supply units to lift or carry routers.
DANGER
Make sure the rack or cabinet housing the router is adequately secured to prevent it from
becoming unstable or falling over.
DANGER
Mount the router in a rack or cabinet as close to the floor as possible. Place the heaviest router
at the bottom and progressively place lighter routers above.
Because of the weight of a fully loaded NetIron XMR 16000 router, it is recommended that you
mount it in a rack before installing modules and AC power supplies.
You can install up to three NetIron XMR 16000 routers in a standard 19-inch (EIA310-D) rack. You
can install your device in a front-mount or a mid-mount configuration using the factory-installed
mounting brackets. For a mid-mount configuration, simply remove the brackets from the front
edges of the device and re-attach them to the center sides of the device using the pre-drilled holes.
You must provide four standard #12-24 pan-head screws for each NetIron XMR 16000 router that
you install in a rack. To perform this task, you will need a #2 Phillips screwdriver.
Follow these steps to mount a NetIron XMR 16000 router in a rack.
1. Determine the position of each router in the rack. For example, mount a router with the fewest
modules near the top, a router with more modules near the middle, and a fully populated
router near the bottom of the rack.
2. Position the four mounting screws for each router in the rack posts according to the spacings
of the keyhole slots (the ones with the narrow portion pointing up) on the mounting brackets as
shown in Figure 109. When tightening the screws, leave approximately 1/4 inch clearance
between the back of the screw head and the rack post.
FIGURE 109 Positioning the mounting screws in a rack
