Brocade MLX Series and NetIron XMR Hardware Installation Guide 205

53-1003821-01

mRJ21 procedures

Cable cinch with four mRJ21 cables

Four mRJ21 cables may be secured as shown in Figure 139.

FIGURE 139 Four mRJ21 cables

Cable cinch with five mRJ21 cables

Five mRJ21 cables may be secured as shown in Figure 140.

FIGURE 140 Five mRJ21 cables
