Removing Brocade MLX-32 router DC power supplies
Follow these steps to remove a 2400W DC power supply in a Brocade MLX-32 router:
1. Ensure the main DC power breaker is OFF.
2. Use a #1 Phillips screwdriver to remove screw that secures the safety cover, as shown in
Figure 86 on page 120. Remove the safety cover.
3. Use a #2 Phillips screwdriver to remove the screws securing the power lugs. Refer to Figure 87
on page 120.
4. Pull down on handle to remove power supply. Refer to Figure 84 on page 117.
Follow these steps to remove a 3000W DC power supply in a Brocade MLX-32 router:
1. Ensure the main DC power breaker is OFF.
2. Use a #1 Phillips screwdriver to remove the screw that secures the safety cover, as shown in
Figure 86 on page 120.
3. Pull down on the handle to remove the 3000W power supply. Refer to Figure 84 on page 117.
4. Use a #2 Phillips screwdriver to remove the screws securing the power lugs. Refer to Figure 87
on page 120.
Final steps
Complete these steps in the order in which they are listed:
• “Attaching a management station”
• “Activating the power source”
• “Verifying proper operation”
Attaching a management station
You can manage your router in the following ways:
• Connect a PC or terminal to the console port on the management module. From this port, you
can assign an IP address to the management module and establish connections through
Telnet or SSH.
• Connect the router to your existing management network and manage the router and other
network devices from a management station.
The management network that you connect to through the 10/100 Ethernet port must be
separate and isolated from the network over which user packets are switched and routed. For
information about functionality on the management port, Refer to “Understanding
management port functions” on page 217.
