Hardware specifications for Brocade MLX routers
8
Physical dimensions
Table 45 provides the physical dimensions for Brocade MLX routers.
Table 46 provides the physical dimensions for Brocade MLXe interface modules.
Operating environment
Table 47 provides the operating environment specifications for Brocade MLX routers.
4-port 10 Gbps Ethernet interface module with fiber-optic transceivers 225W
8-port 10 Gbps Gen 2 Ethernet interface module (M) 248W
4-port 10 Gbps Ethernet interface module (X) 240W
8-port 10 Gbps Ethernet interface module (D) 246W
4-port 40-GbE Ethernet module (M) 320W
20-port Gbps Ethernet fiber Interface with fiber-optic transceivers 175W
20-port Gbps Ethernet copper Interface module 146W
24-port 1 Gbps Ethernet copper RJ45 interface module 160W
24-port 1 Gbps Ethernet fiber interface module 160W
48-port Gbps Ethernet with MRJ-21 interface 260W
Fan assemblies
Brocade MLX-4 fan tray 66W
Brocade MLX-8 fan tray 132W
Brocade MLX-16 front fan tray 202W
Brocade MLX-16 rear fan modules (2 fans) 288W
Brocade MLX-32 fan modules (8 cooling Interface fans, 2 power supply fans) 1150W
TABLE 45 Brocade MLX router physical dimensions
Model Height Width Depth Weight (fully loaded)
Brocade MLX-4 17.68 cm (6.96 in.) 44.32 cm (17.45 in.) 57.15 cm (22.5 in.) 35 kg (78 lbs)
Brocade MLX-8 31.01 cm (12.21 in.) 44.32 cm (17.45 in.) 57.15 cm (22.5 in.) 60 kg (131 lbs)
Brocade MLX-16 62.15 cm (24.47 in.) 44.32 cm (17.45 in.) 64.77 cm (25.5 in.) 107 kg (236 lbs)
Brocade MLX-32 146.58 cm (57.71 in.) 44.32 cm (17.45 in.) 61.21 cm (24.1 in.) 255 kg (561 lbs)
TABLE 46 Brocade MLXe interface modules physical dimensions
Interface module model Height Width Depth Depth with
Fan FRU
Weight
(empty)
Weight
(fully loaded)
BR-MLX-40GX4-M 4.166 cm
(1.46 in.)
18.796 cm
(7.40 in.)
40.64 cm
(16.0 in.)
NA NA 4 kg
(9.85 lbs)
TABLE 44 Maximum power consumption for Brocade MLX router components (Continued)
Component Maximum power
consumption, in watts

Brocade Communications Systems MLX Series Specifications

General

Brand	Brocade Communications Systems
Model	MLX Series
Category	Network Router
Language	English
