Brocade MLX Series and NetIron XMR Hardware Installation Guide 203

53-1003821-01

Chapter

Using Brocade Structured Cabling Components

Cable cinch overview

Position the cable cinch with the open end to the left (no slot) as shown in Figure 136.

FIGURE 136 Cable cinch overview

1 Slot 1 5 Open end

2Slot 2 6Rear

3Slot 3 7Front

4Slot 4

123
