Brocade MLX Series and Brocade NetIron XMR Hardware Installation Guide 95
53-1002373-02
Installing a Brocade MLXe-16 router
2
ver V5.0.0T163
module 1 ni-mlx-20-port-1g-copper
!
This example shows that slot 1 is currently configured for a 20-port 1 Gbps copper
interface module.
b. With the module designation from show running-config command output, use the no
module <slot-number> <module-type> command to remove the configuration from slot 1.
MLXe-16(config)# no module 1 ni-mlx-20-port-1g-copper
This command removes the configuration from slot 1, leaving it ready for a new module.
2. Put on the ESD wrist strap and ground yourself by inserting the plug into the ESD connector on
the chassis.
3. Remove the module from the packaging.
4. Insert the module into the slot, and slide the module along the card guide until the ejectors on
either side of the module rotate towards the module front panel.
NOTE
When inserting a module in the router, make sure that the module faceplate does not overlap
the faceplate of an adjacent module.
5. Rotate the ejectors flush with the module faceplate. This action will fully seat the module in the
backplane.
6. Tighten the two screws on the module faceplate by pushing them in and turning them
clockwise. Complete the tightening process using the flat-blade screwdriver.
7. Ente r t he write memory command to ensure that the slot will be correctly configured for the
new module after a reboot.
Brocade(config)# write memory
Write startup-config done.
