Brocade MLX Series and Brocade NetIron XMR Hardware Installation Guide 131
53-1002373-02
Installing a Brocade MLXe-32 router
2
Cable routing for the lower-left quadrant
1. Route cables from slots #18 and #17 directly to the left through the side comb. Refer to
Figure 95.
FIGURE 95 Routing lower-left quadrant cables
1 Lower left quadrant 3 Cables from slot #18
2 Cables from slot #17 4 Side combs (18)
1
2
3
4
