Brocade MLX Series and Brocade NetIron XMR Hardware Installation Guide 133
53-1002373-02
Installing a Brocade MLXe-32 router
2
Cable routing for the lower-right quadrant
1. Route cables from slots #32 and #31 directly to the right through the side comb. Refer to
Figure 97.
FIGURE 97 Routing the lower-right quadrant cables
1 Lower right quadrant 3 Cables from slot #32
2 Cables from slot #31 4 Side combs (18)
1
2
3
4
