Brocade MLX Series and Brocade NetIron XMR Hardware Installation Guide 335
53-1002373-02
Managing the cooling system
7
Fan Speed Hi: 70 - 113
state = 1 (FAN_STATE_MED)
max_ts_shut_off_count = 1
shut_off_count = 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
=== Thermal Sensor Control Block (THERMAL_SENSOR_TEST_RULE_STANDBY_MP) ===
Fan Speed Low: -1 - 60
Fan Speed Med: 57 - 70
Fan Speed Med-Hi: 67 - 80
Fan Speed Hi: 77 - 85
state = 0 (FAN_STATE_LOW)
max_ts_shut_off_count = 1
shut_off_count = 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
=== Thermal Sensor Control Block (THERMAL_SENSOR_TEST_RULE_MP_CPU) ===
Fan Speed Low: -1 - 60
Fan Speed Med: 57 - 70
Fan Speed Med-Hi: 67 - 80
Fan Speed Hi: 77 - 95
state = 1 (FAN_STATE_MED)
max_ts_shut_off_count = 1
shut_off_count = 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
=== Thermal Sensor Control Block (THERMAL_SENSOR_TEST_RULE_STANDBY_MP_CPU) ===
Fan Speed Low: -1 - 60
Fan Speed Med: 57 - 70
Fan Speed Med-Hi: 67 - 80
Fan Speed Hi: 77 - 95
state = 0 (FAN_STATE_LOW)
max_ts_shut_off_count = 1
shut_off_count = 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Syntax: show fan-threshold
The output displays the following information.
TABLE 50 Temperature threshold information for modules and fan speeds
This field... Displays...
Thermal Sensor Control Block
(THERMAL_SENSOR_TEST_RULE_<
module>)
The temperature threshold information for the various modules. The
<module> parameter indicates the following:
• MP – The active management module
• STANDBY_MP – The standby management module
• SNM – The switch fabric module
• LP – An interface module
Fan Speed Low or Med or Med-Hi or
Hi
The current setting of the low and high temperature thresholds for the low,
medium, medium-high, and high fan speeds.
NOTE: As indicated in Table 49 on page 333, the low fan speed for each
module does not have a default low temperature threshold value,
nor can you configure this value. The “-1” value that appears in the
Fan Speed Low field for each module is a Brocade internal value
only.
State = 0 (FAN_STATE_LOW) For Brocade internal use only.
max_ts_shut_off_count For Brocade internal use only.
shut_off_count = 0 0 0 0 0 0 0 0 For Brocade internal use only.
