Brocade MLX Series and Brocade NetIron XMR Hardware Installation Guide 403
53-1002373-02
Brocade MLXe Chassis bundles
A
BR-MLXE-16-MR-X-AC Bundle contents:
• 1 Brocade MLXe-16 AC chassis
• 1 MR management module
(NI-XMR-MR)
• 3 high speed switch fabric modules
(NI-X-16-8-HSF)
• 4 1200W AC power supply
(NI-X-ACPWR)
• 2 exhaust fan assembly kits
(BR-MLXE-16-FAN)
• 1 air filter
(BR-MLXE-16-FLTR)
Power cord is not included.
BR-MLXE-16-MR-X-DC Bundle contents:
• 1 Brocade MLXe-16 DC chassis
• 1 MR management module
(NI-XMR-MR)
• 3 high speed switch fabric modules
(NI-X-16-8-HSF)
• 4 1200W DC power supply
(NI-X-ACPWR)
• 2 exhaust fan assembly kits
(BR-MLXE-16-FAN)
• 1 air filter
(BR-MLXE-16-FLTR)
Power cord is not included.
BR-MLXE-16-MR2-M-AC Bundle contents:
• 1 Brocade MLXe-16 AC chassis
• 1 MR2 (M) management module
(BR-MLX-MR2-M)
• 3 high speed switch fabric modules
(NI-X-4-HSF)
• 4 1800W AC power supplies
(BR-MLXE-ACPWR-1800)
• 2 exhaust fan assembly kits
(BR-MLXE-16-FAN)
• 1 air filter
(BR-MLXE-16-FLTR)
Power cord is not included.
BR-MLXE-16-MR2-M-DC Bundle contents:
• 1 Brocade MLXe-16 DC chassis
• 1 MR2 (M) management module
(BR-MLX-MR2-M)
• 3 high speed switch fabric modules
(NI-X-4-HSF)
• 4 1800W DC power supplies
(BR-MLXE-DCPWR-1800)
• 2 exhaust fan assembly kits
(BR-MLXE-16-FAN)
• 1 air filter
(BR-MLXE-16-FLTR)
Power cord is not included.
TABLE 71 Brocade MLXe-16 chassis bundles (Continued)
Part number Hardware
