Brocade Communications Systems MLX Series User Manual

Brocade MLX Series and Brocade NetIron XMR Hardware Installation Guide 53
53-1002373-02
Router modules
1
• 32-slot router: Equipped with ten fan assemblies. Each fan assembly contains a 4-speed fan.
The fan trays support four settings, 50%, 60%, 75%, and 100%, as the normal fan speeds,
which are set by the management module.
You can install an optional upward air deflector on the fans of 32-slot routers using a fan
deflector kit from Brocade. For more information, refer to “Cooling system for Brocade MLX
Series and Brocade NetIron XMR routers” on page 57.
Figure 32 and Figure 33 show the fan locations for 4-slot and 8-slot routers. Figure 34 and
Figure 35 show the fan locations for 16-slot routers. Figure 36 shows the fan locations for 32-slot
routers.
FIGURE 32 Fan locations for Brocade MLXe-4 routers
1 Fans in rear of chassis
1
