1 - 5
Outline of Mechanism
Outline of
Mechanism
Outline of
Mechanism
Driveline
(C) Movement of upper blade
Pulley
Driving shaft
Upper knife holder
Upper knife plate assy
Upper knife
Upper knife link
Upper knife arm
Feed bar eccentric wheel
Upper knife arm
Upper knife link
Upper knife
plate assy
Feed bar
eccentric wheel
Upper knife holder
Upper knife
Driving shaft Pulley
