Needle-presser module
Modules
21
Needle bar assy. assembly
1. Attach the needle thread plate 1 to the needle block 2.
2. Attach the needle block 2, needle bar thread guide 3 and support spring
4 using screw 1.
3. Attach the needle block supporter 5 using screw 2.
Start movie clip (CD-ROM version only)
1
2
Torque
0.39 – 0.718 N
−
m
5
1
4
3
2
2
1
2
Needle Clamp Screw
Color; Black
Screw
SM2.38
Color; Silver
