2 - 43
Needle-presser module
Modules
Disassembly
22
Z zigzag cam and shaft removal
1. Remove retaining ring E2, and remove the Z zigzag cam 1.
2. Remove the shaft 2.
Start movie clip (CD-ROM version only)
1
Retaining ring E2
2
23
T cam removal
1. Remove the T cam 1.
Start movie clip (CD-ROM version only)
