Brother HL-L3210CW Service Manual

5-21
Confidential
■ Adjust left-end print position
< Function >
In the event that the left-end print start position deviates, use this function to adjust the position
left and right. The adjustable range is -100 to 750 (1 unit = 0.084 mm = 300 dpi).
< Operating Procedure >
(1) For models with touch panel
Press the [4], and then the [5] in the initial state of maintenance mode. “USBNo.” is
displayed on the LCD.
For models without touch panel
Press the [▲] or [▼] in the initial state of maintenance mode to display
“MAINTENANCE 45” on the LCD, and press the [OK]. “USBNo.” is displayed on the
LCD.
(2) Press the [▲] or [▼] to display “X Adjust” on the LCD, and press the [Mono Start], [SET]
or [OK]. “XAdjust MP” is displayed on the LCD.
(3) Refer to <Adjustment option table> in the table below, press the [▲] or [▼] to select from
the adjustment options, and press the [SET] or [OK]. “XAdj. **= 0*” is displayed on the
LCD. (Selected option is shown for **.)
(4) To shift the writing start position to the left, press the [▼] to decrease the value. To shift
the position to the right, press the [▲] to increase the value.
(5) Press the [Mono Start], [SET] or [OK] after adjusting the value. “Accepted” is displayed on
the LCD.
(6) Press the [X] or [Cancel], and the machine returns to the initial state of maintenance
mode.
<Adjustment option table>
*1
Adjusts first side print start position of the T1. Value of X Adjust DX is added to each tray
adjustment value.
For example, when printing from the T1, it adjusts as “X Adjust DXT1 value” + “X Adjust DX
value” and print. Besides, when the added value is over than the adjustable range (-100 to
750), adjusted value will be for minimum -100 and maximum 750 and does not become out
of adjustable range.
1-sided printing 2-sided printing
Adjustment option LCD Adjustment option LCD
N/A (disabled) X Adjust MP N/A (disabled) X Adjust MP
T1 first side X Adjust T1 T1 second side X Adjust T1
N/A (disabled) X Adjust DX *1 X Adjust DX
N/A (disabled) X Adjust DXMP N/A (disabled) X Adjust DXMP
N/A (disabled) X Adjust DXT1 T1 first side X Adjust DXT1

Brother HL-L3210CW Specifications

General

N-up printing	2, 4, 9, 16, 25
Duplex printing	No
Print technology	LED
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	24 s
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Duplex print speed (black, normal quality, A4/US Letter)	6 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Recommended duty cycle	300 - 1500 pages per month
Number of print cartridges	-
Page description languages	BR-Script 3, PCL 6, PDF, PostScript 3, XPS
Display	LCD
Product color	Gray
Market positioning	Home & office
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPA2-TKIP
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Kindle Fire Printing, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print/Scan), SNTP Client
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, SMTP Client, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, Web Services (Print/Scan)
Paper input type	Cassette, Sheetfed
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	1
Sustainability certificates	Blue Angel, ENERGY STAR
Maximum internal memory	- MB
Sound pressure level (printing)	45 dB
Envelopes sizes	C5, Com-10, DL, Monarch
Custom media width	76.2 - 215.9 mm
Custom media length	116 - 355.6 mm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Package depth	589 mm
Package width	513 mm
Package height	372 mm
Package weight	20700 g
Power consumption (off)	0.04 W
Power consumption (standby)	8.8 W
Power consumption (printing)	390 W
Power consumption (PowerSave)	1 W
Energy Star Typical Electricity Consumption (TEC)	0.9 kWh/week
Standard interfaces	USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cables included	AC
Bundled software	Nuance PaperPort 14 SE
Included black & color (CMYK) cartridges capacity	1000 pages
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	461 mm
Width	410 mm
Height	252 mm
