■ Adjust upper-end print position
< Function >
In the event that the upper-end print start position deviates, use this function to adjust the
position up and down. Adjustable range is -50 to 50 (1 unit = 0.084 mm = 300 dpi).
< Operating Procedure >
(1) For models with touch panel
Press the [4], and then the [5] in the initial state of maintenance mode. “USBNo.” is
displayed on the LCD.
For models without touch panel
Press the [▲] or [▼] in the initial state of maintenance mode to display
“MAINTENANCE 45” on the LCD, and press the [OK]. “USBNo.” is displayed on the
LCD.
(2) Press the [▲] or [▼] to display “Y Adjust” on the LCD, and press the [SET] or [OK].
“YAdjust MP” is displayed on the LCD.
(3) Refer to <Adjustment option table> in the table below, press the [▲] or [▼] to select from
the adjustment options, and press the [SET] or [OK]. “YAdj. **= 0*” is displayed on the
LCD. (Selected option is shown for **.)
(4) To shift the writing start position down, press the [▲] to increase the value. To shift the
position up, press the [▼] to decrease the value.
(5) Press the [SET] or [OK] after adjusting the value. “Accepted” is displayed on the LCD.
(6) Press the [X] or [Cancel], and the machine returns to the initial state of maintenance
mode.
<Adjustment option table>
*1
Adjusts first side print start position of the T1. Value of Y Adjust TRAY and Y Adjust DX is
added to each tray adjustment value.
For example, when printing from the T1, it adjusts as “Y Adjust T1 value” + “Y Adjust TRAY
value” or “Y Adjust DXT1 value” + “Y Adjust DX value” and print. Besides, when the added
value is over than the adjustable range (-50 to 50), adjusted value will be for minimum -50
and maximum 50 and does not become out of adjustable range.
*2
Adjusts second side print start position of the T1. Value of Y Adjust TRAY is added to each
tray adjustment value.
For example, when printing from the T1, it adjusts as “Y Adjust T1 value” + “Y Adjust TRAY
value” and print. Besides, when the added value is over than the adjustable range (-50 to
50), adjusted value will be for minimum -50 and maximum 50 and does not become out of
adjustable range.
1-sided printing 2-sided printing
Adjustment option LCD Adjustment option LCD
N/A (disabled) Y Adjust MP N/A (disabled) Y Adjust MP
T1 first side Y Adjust T1 T1 second side Y Adjust T1
*1 Y Adjust TRAY *2 Y Adjust TRAY
N/A (disabled) Y Adjust DX *1 Y Adjust DX
N/A (disabled) Y Adjust DXMP N/A (disabled) Y Adjust DXMP
N/A (disabled) Y Adjust DXT1 T1 first side Y Adjust DXT1
