Brother HL-L3210CW Service Manual

2-27
Confidential
No Tray T1 Reinstall Tray 1
The T1 paper feed sensor
detected that the T1 is open
when printing from the T1
(before the registration of
printing in the engine).
8501 2-70
The T1 paper feed sensor
detected that the T1 is open
when printing from the T1 (after
the registration of printing in the
engine).
8505 2-70
No Waste
Toner
Install the Waste
Toner Box.
The electrodes of the high-
voltage power supply PCB
detected that no waste toner
box was set.
6300 2-64
Out of
Memory
Press Go for 2
seconds.
The memory is insufficient to
expand the data of PC-Print.
C700 2-80
Print Data Full Print Data is full.
Press Cancel and
delete the
previously stored
data.
The memory used to store
secure print data exceeded the
memory size for secure print
data.
C800 2-80
Print Unable
01
Turn the power off
and then back on
again.
ASIC error or motor driver error
occurred.
0101 2-48
Print Unable
02
Turn the power off
and then back on
again.
Cannot detect the synchronized
signal of the paper feed motor.
The speed of the paper feed
motor does not stabilize within
the specified time.
0201 2-48
Cannot detect the synchronized
signal of the process motor. The
speed of the process motor
does not stabilize within the
specified time.
0202 2-48
Print Unable
05
Turn the power off
and then back on
again.
Detected the fuser unit
temperature error.
0501 2-49
0502 2-49
0503 2-49
0504 2-49
0505 2-49
0506 2-49
050A 2-50
050B 2-50
050C 2-50
Error message
Description
Error
codes
Refer
to:
First line Second line
