Brother MFC-8880DN Service Manual

7-15
Confidential
WSW34 Function setting 12 App. 1-35
WSW35 Function setting 13 App. 1-35
WSW36 Function setting 14 App. 1-36
WSW37 Function setting 15 App. 1-37
WSW38 V.34 transmission settings App. 1-38
WSW39 V.34 transmission speed App. 1-39
WSW40 V.34 modem settings App. 1-40
WSW41 ON-duration of the scanning light source App. 1-42
WSW42 Internet mail settings App. 1-43
WSW43 Function setting 16 App. 1-43
WSW44 Speeding up scanning-1 App. 1-44
WSW45 Speeding up scanning-2 App. 1-45
WSW46
Monitor of power ON/OFF state and parallel port kept at
high
App. 1-46
WSW47 Switching between high- and full-speed USB App. 1-47
WSW48 USB setup latency App. 1-48
WSW49 End-of-copying beep and print in black App. 1-48
WSW50 SDAA settings (Not used) App. 1-49
WSW51 Function setting 17 App. 1-49
WSW52 Function setting 18 App. 1-50
WSW53 Function setting 19 App. 1-50
WSW54 Function setting 20 App. 1-51
WSW55 Not used App. 1-52
WSW56 Function setting 21 App. 1-53
WSW57 Function setting 22 App. 1-54
WSW58 Function setting 23 App. 1-54
WSW59 Function setting 24 App. 1-55
WSW60 Not used App. 1-56
WSW61 Scanning light intensity to judge to be stable 1 App. 1-57
WSW62 Scanning light intensity to judge to be stable 2 App. 1-58
WSW63 Not used App. 1-59
WSW64 Setting the language / Default paper size App. 1-60
WSW65 Setting the paper support App. 1-60
WSW66 Drum life end App. 1-61
WSW67 Not used App. 1-61
WSW68 Fuser unit life end App. 1-61
WSW69 Document scanner unit life end App. 1-61
WSW70 Paper feeding kit life end App. 1-61
WSW71 Paper feeding kit 2 life end App. 1-61
WSW72 Paper feeding kit MP life end App. 1-62
WSW73 Not used App. 1-62
WSW74
The limited number of the documents in order for paper
ejection of the simplex scanning from ADF.
App. 1-62
WSW75 Paper eject distance of switch back App. 1-63
WSW No. Function Refer to:

Brother MFC-8880DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16
Time to first copy (black, normal)	10.5 s
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Card reader integrated	No
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Business
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Print, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	Scan
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Recycled paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	85 W
Power consumption (PowerSave)	18 W
Power consumption (average operating)	680 W
Maximum duty cycle	- pages per month
Package weight	22100 g
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Ultimate, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
