Installation and Connections
MATRIX CUBE - 24 -
3) Thread the yarn through wheels (R1) and (R2), as indicated on the following figure:
4) Thread the yarn through wheels (R3) and (R4), as indicated on the following figure.
5) Bring the yarn up to the application point on production line, passing through the intermediate wheels
provided along the path (if any).
Wheel (R1)
Wheel (R2)
Wheel (R3)
Wheel (R4)
