123
Operating and functions
VALiD Y/N
→ To exit the function, confirm "VALID N".
→ To restore the default configuration of the device, confirm
"VALID Y".
FACt. SEt
REtURN
CONFiG.
Fig. 102 : Restoring the default configuration of the device
Tab. 10 : Default configuration of the device
Function Default value
LANGUAGE English
Dosing UNITS litre
UNIT of the flow rate l/s
UNIT of the totalizers litre, 0 decimals
K FACTOR 1.00
OPTIONAL dosing mode "LOC. MANU"
V1 to V7=0.00
Parameters A and B for dosing mode "EXT. [T]" 0
Teach-In dosing quantity for dosing modes "EXT. REP."
and "LOC. REP."
0
OVERFILL CORRECTION yes, direct, tolerance 0
ALARME during dosing no
Time delay = 1s
ALARME at the end of the dosing no
Time delay = 1s
OUTPUT DO1 Pulse, PU=0.0
Litre
OUTPUT DO2 Valve 100%, not inverted, time delay before opening =
0 s
OUTPUT DO3 Alarm, not inverted
OUTPUT DO4 State
ERR10Hz inactive
BACKLIGHT level 9, activated for 30s
FLOW-WARNING W- = W+ = 0.000
Time delay = 1s
VOLUME-WARNING 0
BATCH-WARNING 0
→ If you do not want to adjust another parameter, confirm the "END" parameter to save the settings or not and
go back to the Process level.
English
Type 8025 - 8035 - SE35 BATCH
