Burkert 8035 - Doing a Dosing in Dosing Mode LOC. MEM. or MEM.+MANU

71
Operating and functions
→ To interrupt the dosing, press
ENTER
: the valve connected to output DO2 and possibly the valve connected
to output DO3 close, the device state LED flashes at a 1 Hz-frequency and the DO4 output (if configured to
transmit the device state, see chap. 10.7.26) generates a 1 Hz-frequency.
CONtiNUE
0......9
RESEt
→ Confirm to continue the dosing.
→ Confirm to abort the dosing.
87.2 L
The countdown of the dosing quantity continues.
0100.0 L
The device is ready for a new dosing.
Fig. 41 : Interrupting the dosing in dosing modes "LOC. MANU." or "MEM.+MANU."
10.6.2 Doing a dosing in dosing mode "LOC. MEM." or
"MEM.+MANU."
Dosing mode "LOC. MEM." allows for starting the dosing, via the navigation keys, of a quantity saved in the
memory.
Dosing mode "MEM.+MANU." allows for:
• either entering a dosing quantity and starting the dosing, via the navigation keys,
• or selecting a dosing quantity from the memory and starting the dosing, via the navigation keys,
Danger
Danger due to electrical voltage.
▶ Disconnect the electrical power for all the conductors and isolate it before carrying out work on the system.
▶ Observe all applicable accident protection and safety regulations for electrical equipment.
→ Connect the valves to the DO2 and DO3 outputs: see chap. 8.14.
→ Wire the output DO4 as described in Fig. 39, chap. 10.6.1.
→ Start the device again.
→ Configure the device with the dosing mode "LOC. MEM." or "MEM.+MANU.": see chap. 10.7.7 or 10.7.8.
→ Do a dosing as shown in Fig. 42.
English
Type 8025 - 8035 - SE35 BATCH
