19
Technical data
• protection • galvanically insulated, and protected against over-
voltages, polarity reversals and short-circuits
Relay output DO2 and DO3
• operating • hysteresis, adjustable thresholds, normally open
• DO2 function • valve 100%, cannot be modified
• DO3 function • alarm (can be configured and parametered)
• electrical data of the load
(non UL recognized devices)
• 230 V AC / 3 A or
40 V DC / 3 A (resistive load)
• electrical data of the load
(UL recognized devices)
• max. 30 V AC and 42 V peak / 3 A or
max. 60 V DC / 1 A
Digital inputs DI1 to DI4
• commutation threshold V
on
• 5...36 V DC
• commutation threshold V
off
max. • 2 V DC
• min. pulse duration • 100 ms
• input impedance • 9,4 kW
• protection • galvanically isolated, and protected against polarity
reversals and voltage spikes
6.2 Technical data of the dosing controller 8025 Batch
in panel version
6.2.1 Conditions of use of a 8025 Batch in panel version
Ambient temperature
• non-UL version • –10...+60°C
• UL and CSA version • 0...+40°C
Air humidity
< 80%, non condensated
Protection rating according to EN 60529
• front side • IP65, installation completed and closed cabinet
• non-front side • IP20 in the closed cabinet
Degree of pollution (UL and CSA recognized version)
Degree 2 according to EN 61010 -1
Installation category (UL and CSA recognized version)
Category I according to UL61010-1 - Indoor use
Max. height above sea level
2000 m
6.2.2 Conformity to standards and directives of a 8025 Batch in
panel version
The applied standards, which verify conformity with the EU Directives, can be found on the EU Type Examination
Certificate and/or the EU Declaration of Conformity (if applicable).
UL-Certification
Finished products with variable key PU01 or PU02 are UL-certified products and comply also with the following
standards:
• UL 61010-1
• CAN/CSA-C22.2 n°61010-1
English
Type 8025 - 8035 - SE35 BATCH
