Operating and functions
10 OPERATING AND FUNCTIONS
10.1 Safety instructions
Danger
Danger due to electrical voltage.
▶ Disconnect the electrical power for all the conductors and isolate it before carrying out work on the system.
▶ Observe all applicable accident protection and safety regulations for electrical equipment.
Warning
Risk of injury due to non-conforming operating.
Non-conforming operating could lead to injuries and damage the device and its surroundings.
▶ The operators in charge of operating must have read and understood the contents of these operating
instructions.
▶ In particular, observe the safety recommendations and intended use.
▶ The device/installation must only be operated by suitably trained staff.
10.2 Operating levels of the device
The device has two operating levels: the Process level and the Configuration level.
The Process level allows for:
• starting a dosing.
• reading the values of the main and daily totalizers of the quantity of fluid counted since the last reset.
• reading the values of the main and daily totalizers of the done dosings since the last reset.
• resetting the daily volume or mass totalizer:
• resetting the daily totalizer of the done dosings.
• accessing the Configuration level.
The Configuration level comprises four menus (Parameters, Test, Information and History) and allow for:
• seting the device parameters.
• setting the dosing mode on the device.
• doing the Teach-In of the quantity to be dosed (only if dosing modes "LOC. REP" or "EXT. REP" are active on
the device).
• testing the inputs and the outputs of the device.
• reading and confirming, when the device state LED is orange or red and when no dosing is being done, the
warning and fault messages generated by the device.
• consulting the history of the last 10 dosings.
English
Type 8025 - 8035 - SE35 BATCH
