Electrical installation and Wiring
8.11 Wiring the DO1 transistor output of device, fed with
12...36 V DC
NPN wiring PNP wiring
PE PEPE
L+ L- PE P- P+
NC
Iout
PULSE
DO1
Supply
12..36Vdc
Univ
Batch
(AO1)
300 mA
+
-
12-36 V DC
(*)
+
-
+
-
5-36 VDC
PLC
Power supply
of the device
Power supply
of the device
PLC
PE PEPE
L+ L- PE P- P+
NC
Iout
PULSE
DO1
Supply
12..36Vdc
Univ
Batch
(AO1)
300 mA
(*)
+
-
+
-
5-36 VDC
+
-
12-36 V DC
*) If a direct earth connection is not possible, fit a 100 nF/50 V capacitor between the negative power supply terminal and the earth
Fig. 35 : NPN or PNP wiring of the DO1 transistor output of the device
→ Configure transistor output DO1 acc. to chap. 10.7.19 to 10.7.23.
8.12 Wiring the DO1 transistor output of a version fed
with 115/230 V AC for the 8025 Batch in compact
version, for the 8035 Batch or for the SE35 Batch
→ Wire the transistor output DO1 as described in chap. 8.11.
→ Configure transistor output DO1 acc. to chap. 10.7.19 to 10.7.23.
