Burkert 8035 - Wiring Digital Inputs;Output DO4

55
Electrical installation and Wiring
Type of signal
emitted by the
remote flow
sensor
Selector
"SENSOR
TYPE"
C
Selector
"SENSOR
SUPPLY"
A
Selector "LOAD"
B
LOAD
COIL/PNP
39K
470
2.2K
Terminal assignment of
terminal block "FLOW
SENSOR"
FLOW
SENSO
R
SUPPLY
NC
COIL
PULSE
INPUT
NPN/PNP
2
13PE
+-
pulse, NPN
→ Set the
selector on
"NPN/PNP"
(Fig. 33)
→ Set the
selector as
shown in
Fig. 34.
→ Set selector "LOAD":
• either on "2.2k": the load
resistance R is then 2,2 kW
• either on "470": the load
resistance R is then 470 W
213PE
8025
R
+3 V
Flow sensor
"on/off" signal
(Reed relay for
example)
→ Set the
selector on
"NPN/PNP"
(Fig. 33)
→ Set the
selector as
shown in
Fig. 34.
→ Set selector "LOAD":
• either on "2.2k": the load
resistance R is then 2,2 kW
• either on "470": the load
resistance R is then 470 W
213PE
8025
R
+3 V
...
Flow sensor
8.10 Wiring the digital inputs DI1 to DI4 and the
transistor output DO4
Wiring of the digital inputs DI1 to DI4 and wiring of the transistor output DO4 are described in chap. 10.6.1 to
10.6.7, because they depend on the dosing mode configured.
English
Type 8025 - 8035 - SE35 BATCH
